“Logging in” to AWS ECS Fargate

I’m a big fan of AWS ECS Fargate. I’ve written in the past about managing ECS clusters, and with Fargate — all of that work disappears and is managed by AWS instead. I like to refer to this as quasi-serverless. Sorta-serverless? Almost-serverless? I’m open to better suggestions. 😂

There are a few limitations of running in Fargate, and this blog post will focus on working around one limitation: there’s easy way to get an interactive command line shell within a running Fargate container.

The way I’m going to establish an interactive session inside Fargate is similar to how CircleCI or Heroku does this: start a SSH server in the container. This requires two components: the SSH server itself, which will be running in Fargate, and a tool to automate launching the SSH server. Most of this blog post will be about the tool to automate launching the server, called ecs-fargate-login.

If you want to skip to the code, I’ve made it available on GitHub using the MIT license, so feel free to use it as you wish.

How it works

This is what ecs-fargate-login does for you, in order:

  1. Generate a temporary SSH key pair.
  2. Use the ECS API to start a one-time task, setting the public key as an environment variable.
    • When the SSH server boots, it reads this environment variable and adds it to the list of authorized keys.
  3. Poll the ECS API for the IP address of the running task. ecs-fargate-login supports both public and private IPs.
  4. Start the ssh command and connect to the server.

When the SSH session finishes, ecs-fargate-login will make sure the ECS task is stopping.

Use cases

Most of my clients use Rails, and Rails provides an interactive REPL (read-eval-print loop) within the Rails environment. This REPL is useful for running one-off commands like creating new users or fixing some data in the database, checking and/or clearing cache items, to mention a few common tasks. Rails developers are accustomed to using the REPL, so while not entirely necessary (in the past, I usually recommended fixing data using direct database access or with one-time scripts in the application repository), it is a nice-to-have feature.

In conclusion

I don’t use this tool daily, but probably a few times a week. A few clients of mine use it as well, and they’re generally happy with how it works. However, if you have any recommendations about how it could be improved, or how the way the tool itself is architected could be improved, I’m always open to discussion. This was my first serious attempt at writing Golang code, so there are probably quite a few beginner mistakes in the code, but it should work as expected.

Categories
AWS English

Managing ECS clusters, 4 years in.

Throughout these past 4 years since AWS ECS became generally available, I’ve had the opportunity to manage 4 major ECS cluster deployments.

Across these deployments, I’ve built up knowledge and tools to help manage them, make them safer, more reliable, and cheaper to run. This article has a bunch of tips and tricks I’ve learned along the way.

Note that most of these tips are rendered useless if you use Fargate! I usually use Fargate these days, but there are still valid reasons for managing your own cluster.

Spot Instances

ECS clusters are great places to use spot instances, especially when managed by a Spot Fleet. As long as you handle the “spot instance is about to be terminated” event, and set the container instance to draining status, it works pretty well. When ECS is told to drain a container instance, it will stop the tasks cleanly on the instance and run them somewhere else. I’ve made the source code for this Lambda function available on GitHub.

Just make sure your app is able to stop itself and boot another instance in 2 minutes (the warning time you have before the spot instance is terminated). I’ve experienced overall savings of around 60% when using a cluster exclusively comprised of spot instances (EBS is not discounted).

Autoscaling Group Lifecycle Hooks

If you need to use on-demand instances for your ECS cluster, or you’re using a mixed spot/on-demand cluster, I recommend using an Autoscaling Group to manage your cluster instances.

To prevent the ASG from stopping instances with tasks currently running, you have to write your own integration. AWS provides some sample code, which I’ve modified and published on GitHub.

The basic gist of this integration is:

  1. When an instance is scheduled for termination, the Autoscaling Group sends a message to an SNS topic.
  2. Lambda is subscribed to this topic, and receives the message.
  3. Lambda tells the ECS API to drain the instance that is scheduled to be terminated.
  4. If the instance has zero running tasks, Lambda tells the Autoscaling Group to continue with termination. The Autoscaling Group terminates the instance at this point.
  5. If the instance has more than zero running tasks, Lambda waits for some time and sends the same message to the topic, returning to step (2).

By default, I set the timeout for this operation to 15 minutes. This value depends on the specific application. If your applications require more than 15 minutes to cleanly shut down and relocate to another container instance, you’ll have to set this value accordingly. (Also, you’ll have to change the default ECS StopTask SIGTERM timeout — look for the “ECS_CONTAINER_STOP_TIMEOUT” environment variable)

Cluster Instance Scaling

Cluster instance scale-out is pretty easy. Set some CloudWatch alarms on the ECS CPUReservation and MemoryReservation metrics, and you can scale out according to those. Scaling in is a little more tricky.

I originally used those same metrics to scale in. Now, I use a Lambda script that runs every 30 minutes, cleaning up unused resources until a certain threshold of available CPU and memory is reached. This technique further reduces service disruption. I’ll post this on GitHub sometime in the near future.

Application Deployment

I’ve gone through a few application deployment strategies.

  1. Hosted CI + Deploy Shell Script
    • Pros: simple.
    • Cons: you need somewhere to run it, easily becomes a mess. Shell scripts are a pain to debug and test.
  2. Hosted CI + Deploy Python Script (I might put this on GitHub sometime)
    • Pros: powerful, easier to test than using a bunch of shell scripts.
    • Cons: be careful about extending the script. It can quickly become spaghetti code.
  3. Jenkins
    • Pros: powerful.
    • Cons: Jenkins.
  4. CodeBuild + CodePipeline
    • Pros: simple; ECS deployment was recently added; can be managed with Terraform.
    • Cons: Subject to limitations of CodePipeline (pretty limited). In our use case, the sticking points are not being able to deploy an arbitrary Git branch (you have to deploy the branch specified in the CodePipeline definition).

Grab-bag

Other tips and tricks

  • Docker stdout logging is not cheap (also, performance is highly variable across log drivers — I recently had a major problem with the fluentd driver blocking all writes). If your application blocks on logging (looking at you, Ruby), performance will suffer.
  • Having a few large instances yields more performance than many small instances (with the added benefit of having the layer cache when performing deploys).
  • The default placing strategy should be: binpack on the resource that is most important to your application (CPU or memory), AZ-balanced
  • Applications that can’t be safely shut down in less than 1 minute do not work well with Spot instances. Use a placement constraint to make sure these tasks don’t get scheduled on a Spot instance (you’ll have to set the attribute yourself, probably using the EC2 user data)
  • Spot Fleet + ECS = ❤️
  • aws update-service help for service administration commands. I use --force-new-deployment and --desired-count quite often.
  • If you manage your own EC2 instances with Auto Scaling Groups: aws autoscaling terminate-instance-in-auto-scaling-group --instance-id "i-XXX" --no-should-decrement-desired-capacity will start a new EC2 instance and perform termination lifecycle hooks on it. This is what I use to switch out old EC2 instances with new launch configurations.
